Product Features
Improving Efficiency: Component-level MPPT tracking, increasing system power generation by 5-25%
Safety Shutdown: Automatically shutdown in case of overvoltage, overcurrent, or overtemperature, supporting local and remote shutdown to eliminate high voltage danger
Accurate Monitoring: Real-time monitoring of each component's operating data to promptly identify problematic components
Convenient Installation: Can be directly connected to existing PV systems without changing the original wiring
Long Lifespan: Designed for a 25-year lifespan, matching with PV modules
Product Features
Improving Efficiency: Component-level MPPT tracking, increasing system power generation by 5-25%
Safety Shutdown: Automatically shutdown in case of overvoltage, overcurrent, or overtemperature, supporting local and remote shutdown to eliminate high voltage danger
Accurate Monitoring: Real-time monitoring of each component's operating data to promptly identify problematic components
Convenient Installation: Can be directly connected to existing PV systems without changing the original wiring
Long Lifespan: Designed for a 25-year lifespan, matching with PV modules
Parameters
Model |
Honeybee400 |
Honeybee650 |
Honeybee850 |
|
Input Parameter |
||||
Maximum Input Power |
450 W |
650 W |
850 W |
|
Maximum Input Voltage |
75 VDC |
75 VDC |
60 VDC |
|
Working Voltage Range |
12~75 VDC |
12~75 VDC |
14~60 VDC |
|
MPPT Voltage Range |
12~75 VDC |
12~75 VDC |
14~60 VDC |
|
Short-circuit Current(Isc) |
15 A |
16 A |
23 A |
|
Maximum Input Current |
13 A |
15 A |
21 A |
|
Maximum Output Power |
450W |
650W |
850 W |
|
Voltage Range |
0~75 VDC |
0~75 VDC |
0~60 VDC |
|
Maximum Output Current |
13 A |
15 A |
21 A |
|
Maximum Conversion Efficiency |
99.50% |
99.50% |
99.50% |
|
Other |
||||
Maximum System Voltage |
1500 VDC |
|||
Operation Temperature |
-40~+85℃ |
|||
Relative Humidity Protection Level |
0~100% IP68 |
|||
Protection Level |
IⅡ |
|||
Communication Model |
868M/915M/2.4G/PLC |
|||
Installation Specifications |
||||
Cable Length (input/output) |
Input: 200 mm/Output: 1000 mm (customizable) |
|||
Size |
130.3x109.6x25 mm |
|||
Weight |
520 g |
|||
Connector (input/output) |
Compatible with MC4、Staubli |
|||
Standard/Certification |
||||
Secure |
IEC/EN 62109-1:2010 |
|||
EMC |
EN 61000-6-1:2007 EN 61000-6-3:2007/+A1:2011 |
|||
Communication |
EN 50663:2017, EN 62479:2010 |
※Honeybee 650-PLC and Honeybee 850-PLC work status can be customized (default on or default off)
